All core components are imported from Taiwan to ensure premium quality.
The spindle is made of high-performance materials, offering superior shock resistance and wear resistance.
The worktable features high precision, low error tolerance, strong load-bearing capacity, and exceptional stability.I. Core Common Features
1，Brand Positioning: Standard Manual Milling Machine series.,
2，Key Advantages:
A, All core components are imported from Taiwan to ensure premium quality.
B,The spindle is made of high-performance materials, offering superior shock resistance and wear resistance.
C, The worktable features high precision, low error tolerance, strong load-bearing capacity, and exceptional stability.
II. Model Differentiation Comparison Table
Product Name | Standard Manual Milling Machine M3 | Standard Manual Milling Machine M3 | Standard Manual Milling Machine M3 | ||
Model | E3 | E4 | E5 | ||
Worktable Size (L×W) | 10''×50''/10''×54'' | 10''×50''/10''×54'' (1270×254mm/1370×254mm) | 1370×305mm | ||
(1270×254mm/1370×254mm) | |||||
Max. Worktable Load | 300kgs | 300kgs | 300kgs | ||
Axis Travel (X×Y×Z) | 760×350×350mm | 800×350×350mm | 710×400×380mm | ||
Spindle Nose to Worktable | 75-405mm | 75-405mm | 110-480mm | ||
Overarm Travel | 430mm | 380mm | 490mm | ||
Quill Feed | 127mm | 127mm | 127mm | ||
Quill Feed Speed | 0.04/0.08/0.15mm/rev | 0.04/0.08/0.15mm/rev | 0.04/0.08/0.15mm/rev | ||
Spindle Speed (RPM) | 16 steps, 65-4660rpm | 16 steps, 85-5440rpm | 16 steps, 85-5440rpm | ||
Spindle Taper | R8 (NT30) | R8 (NT30) | NT40 | ||
Spindle Motor Power | 3HP | 3HP | 5HP | ||
Head tilt | Back-forth/Right-left 45° | ||||
Guiding tracks: X.Y.Z | ▲.▲.▲ | ▲.◼.▲ | ▲.◼.◼ | ||
Machine Dimensions (L×W×H) | 1750×1700×2100mm | 1750×1700×2100mm | 1850×2000×2250mm | ||
Machine Weight | 1050KGS | 1050KGS | 1650KGS | ||
Standard Accessories | *Linear Scale DRO Kits *Protecting rubber | *Axis-X&Y(D、R、O) | *Axis-X&Y(D、R、O) *58pcs Clamping kits | ||
Optional Accessories | *Water Pump | Same as E3 | Same as E3 (note spindle taper compatibility) | ||
III. Key Differentiation Explanations
1，Worktable and Travel:
E3: Offers two worktable lengths (50''/54'') with consistent X-axis travel (760mm), suitable for versatile workpiece sizes.
E4: Fixed 1270mm (50'') worktable length with extended X-axis travel (800mm), ideal for wider machining applications.
E5: Wider worktable (305mm) and larger Y/Z-axis travel (400mm/380mm), optimized for 3D machining or large workpieces.
2，Spindle Performance:,
E3/E4: R8 (NT30) spindle taper with 3HP motor, suitable for medium-speed machining tasks.
E5: Upgraded to NT40 taper and 5HP motor, providing higher torque for heavy-duty cutting or high-precision operations.
3，Machine Size and Weight:
E3/E4: Identical dimensions and weight, fitting small-to-medium workshops or space-constrained environments.
E5: More compact footprint (reduced length/width) but increased height and weight, ensuring robust stability for large-scale operations.
4，Accessory Configuration:
E3: Standard linear scale DRO kits enhance positioning accuracy.
E4/E5: Pre-installed X&Y axis DRO systems, with Z-axis scale available as an optional upgrade.
